6
89
If the Motor pot up and Motor pot down commands are given at the same time, they will not change the speed
reference value. The last speed reference value is saved when the drive is switched off or if there is a fault. When
the drive is restarted, it accelerates to this speed according to the ramp set. If the command Motor pot reset is
given with the drive switched off, the speed reference value is deleted and the drive starts at zero speed. If the
status of theMotor pot sign command is changed while the drive is running, the drive will reverse according
to the specified ramp times.
When using the motor potentiometer function, the ramp must be enabled and the Start command must be present.
6.14.2 Jog function
FUNCTIONS
Jog function
[244] Enable jog
[265] Jog operation
[375] Jog selection
[266] Jog reference [FF]
Parameter description No.
Value
Standard
Configuration min max
Factory
American
Factory
European
Enable jog
Enabled (1) / Disabled (0)
244 0 1 Disabled Disabled -
Jog operation 265 - - - -
Jog selection
Speed input (0) / Ramp input (1)
375 0 1 0 0 -
Jog reference [FF] 266 0 32767 0 0 **
Jog +
No jog forwards (0)
Forwards jog (1)
398 0 1 *
Jog -
No backwards jog (0)
Backwards jog (1)
399 0 1 *
* This function can be assigned to one of the programmable digital inputs.
** This parameter can be assigned to a programmable analog input.
Enable jog Enabled Enabled Jog function (this selection is possible only when the
drive is switched off).
Disabled Disabled Jog function
Jog operation Pressing the “+” and “-” keys on the keypad enables the drive to be moved forward and
backward. In connection with the 6KDV3 ... Q4 converters it is possible to operate the
Jog function in an anti-clockwise rotation by pressing the “-” key.
+ Jog clockwise rotation
- Jog counter-clockwise rotation
Jog reference Reference value for jog mode. Defined by the units, specified by the factor function.
Jog selection This parameter determines if the Jog function reference must go through the ramp or
directly to the speed regulator.
Speed input The Jog reference is directly defined. The ramp is not active.
Ramp input The Jog reference is defined with a set ramp.
Jog + High Clockwise Jog function when the Jog function is enabled and
the Start command is not present.
Low Disabled
Jog - High Counter-clockwise Jog function for the 6KDV3 ... Q4 when the
Jog function is enabled and the Start command is not present.
