GEI-100332Ga
——— DESCRIPTION, COMPONENT IDENTIFICATION AND SPECIFICATIONS ———
2
8
2.4 SpECIFICATIONS
2.4.1 Standards
General: EN 61800-1, EN 50178.
Climatic conditions: IEC 68-2 part 2 and 3 (EN 60068-2-2, test Bd).
Isolations distances: IEC 664, IEC 664 A; Environment pollution degree 2.
Interference immunity: EN 61000-4-4, Interference immunity level 4
EN 61000-4-2, Interference immunity level 6 kV CD / 8 kV AD.
Oscillation test: EN 60068-2-6, test Fc.
EMC compatibility: EN 68100-3, see information in “EMC Guidelines”.
Safety: EN 50178.
Protection degree: EN 60529.
UL approvation: According to file No. E 61641 for approved drives series.
2.4.2 AC Input
Table 2.4.2.1: AC input votages
DC Drive series Power section Field circuit Power supply regulation section
(U/V/W terminals) (U1/V1 terminals) (U2/V2 terminals)
230 V ±10 %*, 3Ph
6KDV3...Q2A 400 V ±10 %*, 3Ph
6KDV3...Q4E
50/60 Hz ±5 % 230 V ±10 %*, 1Ph 115 V ±15 % **, 1Ph
230 V ±10 %*, 3Ph 400 V ±10 %*, 1Ph or
400 V ±10 %*, 3Ph 460 V ±10 %, 1Ph 230 V ±15 % **, 1Ph
440 V ±10 %, 3Ph
6KDV3...Q2B 460 V ±10 %, 3Ph 50/60 Hz ±5 % 50 / 60 Hz ±5 %
6KDV3...Q4F 480 V ±10 %, 3Ph
500 V ±10 %, 3Ph
50/60 Hz ±5 %
Gd030ge
* With the indicated tolerance values the output voltage complies the DIN 40030 standard.
With wider tolerances the max output voltage chenges accordingly.
** To work at 115 V with drives from 224 Amps and above a jumper between terminals SA - SB
(placed on the rear size of the drive) must be inserted.
