DV-300 Adjustable Speed Drives
——— FUNCTION DESCRIPTION ———
6
133
Pad A Bit 3 523 0 1 0 0 ***, ****
Pad A Bit 4 524 0 1 0 0 ***, ****
Pad A Bit 5 525 0 1 0 0 ***, ****
Pad A Bit 6 526 0 1 0 0 ***, ****
Pad A Bit 7 527 0 1 0 0 ***, ****
Pad A Bit 8 528 0 1 0 0
Pad A Bit 9 529 0 1 0 0
Pad A Bit 10 530 0 1 0 0
Pad A Bit 11 531 0 1 0 0
Pad A Bit 12 532 0 1 0 0
Pad A Bit 13 533 0 1 0 0
Pad A Bit 14 534 0 1 0 0 *****
Pad A Bit 15 535 0 1 0 0
Bitword pad B 536 0 65535 0 0 ****
Pad B Bit 0 537 0 1 0 0 ****
Pad B Bit 1 538 0 1 0 0 ****
Pad B Bit 2 539 0 1 0 0 ****
Pad B Bit 3 540 0 1 0 0 ****
Pad B Bit 4 541 0 1 0 0 ****
Pad B Bit 5 542 0 1 0 0 ****
Pad B Bit 6 543 0 1 0 0 ****
Pad B Bit 7 544 0 1 0 0 ****
Pad B Bit 8 545 0 1 0 0
Pad B Bit 9 546 0 1 0 0
Pad B Bit 10 547 0 1 0 0
Pad B Bit 11 548 0 1 0 0
Pad B Bit 12 549 0 1 0 0
Pad B Bit 13 550 0 1 0 0
Pad B Bit 14 551 0 1 0 0 *****
Pad B Bit 15 552 0 1 0 0
* These parameters can be set on a programmable analog inputs.
** These parameters can be set on a programmable analog output.
*** These parameters can be set on a programmable digital input.
**** These parameters can be set on a programmable digital output.
***** These parameters can be set on Relay 2.
Pad 0...15 General variables, 16 Bit. The Pads 0...3 can be set via analog inputs. The values of the
Pads 0, 1, 4 , 5 and 6 can be set on analog outputs.
Bitword pad A (B) Bitmap of the parameters Pad A (B) bit 0 up to Pad A (B) bit 15. With a parameter it
is possible to read or write all the Bits inside a Word.
Example: Pad A bit 0 0
Pad A bit 1 1 = 2 1 =2
Pad A bit 2 0
Pad A bit 3 0
Pad A bit 4 0
Pad A bit 5 1 = 2 5 = 32
Pad A bit 6 1 = 2 6 = 64
Pad A bit 7 0
Pad A bit 8 0
