DV-300 Adjustable Speed Drives
——— PARAMETER LISTS ———
10
37
Digital I/Q - - ü - - -
Speed min amount [FF] 1 U32 0 232-1 0 0 ü R/Z - -
Speed max amount [FF] 2 U32 0 232-1 5000 5000 ü R/Z - -
Speed max pos [FF] 3 U32 0 232-1 5000 5000 ü R/Z - -
Speed max neg [FF] 4 U32 0 232-1 5000 5000 ü R/Z - -
Speed min pos [FF] 5 U32 0 232-1 0 0 ü R/Z - -
Speed min neg [FF] 6 U32 0 232-1 0 0 ü R/Z - -
T current lim [%] 7 U16 0 200 150 150 ü R/W IA R/W
T current lim + [%] 8 U16 0 200 150 150 ü R/W IA R/W
T current lim - [%] 9 U16 0 200 150 150 ü R/W IA R/W
In use Tcur lim+ [%] 10 U16 0 200 ü R - R
In use Tcur lim- [%] 11 U16 0 200 ü R - R
Current lim red [%] 13 U16 0 200 100 100 ü R/W - R/W
Ramp shape
Linear
S-Shaped
18 U16 0 1 Linear
(0)
Linear
(0)
ü R/Z
0
1
- -
S shape t const [ms] 19 Float 100 3000 300 300 ü R/W - -
Ramp +/- delay [ms] 20 U16 0 65535 100 100 ü R/W - -
Acc delta speed [FF] 21 U32 0 232-1 100 100 ü R/W - -
Acc delta time [s] 22 U16 0 65535 1 1 ü R/W - -
Acc delta speed1 [FF] 23 U32 0 232-1 100 100 ü R/W - -
Acc delta time 1 [s] 24 U16 0 65535 1 1 ü R/W - -
Acc delta speed2 [FF] 25 U32 0 232-1 100 100 ü R/W - -
Acc delta time 2 [s] 26 U16 0 65535 1 1 ü R/W - -
Acc delta speed3 [FF] 27 U32 0 232-1 100 100 ü R/W - -
Acc delta time 3 [s] 28 U16 0 65535 1 1 ü R/W - -
Dec delta speed [FF] 29 U32 0 232-1 100 100 ü R/W - -
Dec delta time [s] 30 U16 0 65535 1 1 ü R/W - -
Dec delta speed1 [FF] 31 U32 0 232-1 100 100 ü R/W - -
Dec delta time 1 [s] 32 U16 0 65535 1 1 ü R/W - -
Dec delta speed2 [FF] 33 U32 0 232-1 100 100 ü R/W - -
Dec delta time 2 [s] 34 U16 0 65535 1 1 ü R/W - -
Dec delta speed3 [FF] 35 U32 0 232-1 100 100 ü R/W - -
Dec delta time 3 [s] 36 U16 0 65535 1 1 ü R/W - -
QStp delta speed [FF] 37 U32 0 232-1 1000 1000 ü R/W - -
QStp delta time [s] 38 U16 0 65535 1 1 ü R/W - -
T current ref 1 [%] 39 I16 -200 +200
see 6.4.3
0 0 ü R/W IA, QA R/W
T current ref 2 [%] 40 I16 -200 +200 0.00 0.00 ü R/W IA, QA -
T current ref [%] 41 I16 -200 +200 - - ü R QA R
Speed ref 1 [FF] 42 I16 -2 P45 +2 P45 0 0 ü R/W IA, QA R/W
Speed ref 2 [FF] 43 I16 -2 P45 +2 P45 0 0 ü R/W IA, QA R/W
Ramp ref 1 [FF] 44 I16 -2 P45 +2 P45 0 0 ü R/W IA, QA R/W
Speed base value [FF] 45 U32*** 1 16383 1500 1500 ü R/Z - R
Speed input perc [%] 46 I16 -32768 +32767 0 0 ü R/W - R/W
Ramp ref 1 (%) 47 Float -200.0 +200.0 0.0 0.0 ü R/W - -
Parameter No. Format
Value Access via
min max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
10.2 NuMERICAL LIST
