DV-300 Adjustable Speed Drives
——— PARAMETER LISTS ———
10
81
10.4 LIST OF hIGh pRIORITY pARAMETERS
When a 6KCV300DGF is used a subset of the DV-300 parameters can be exchanged with the optional card through
the automatic synchronous communication. For more details see the 6KCV300DGF technical documentation.
Parameter No. Format Value Read/
Write
min max factory
T current lim + [CURR] 8 U16 0 2 * TOP_CURR TOP_CURR R/W
T current lim - [CURR] 9 U16 0 2 * TOP_CURR TOP_CURR R/W
In use Tcur lim+ [CURR] 10 U16 0 2 * TOP_CURR - R
In use Tcur lim- [CURR] 11 U16 0 2 * TOP_CURR - R
Current lim red [CURR] 13 U16 0 2 * TOP_CURR TOP_CURR R
T current ref 1 [CURR] 39 I16 -2 * TOP_CURR +2 * TOP_CURR 0 R/W
T current ref 2 [CURR] 40 I16 -2 * TOP_CURR +2 * TOP_CURR 0 R/W
T current ref [CURR] 41 I16 -2 * TOP_CURR +2 * TOP_CURR - R
Speed ref 1 [SPD] 42 I16 -32767 32767 0 R/W
Speed ref 2 [SPD] 43 I16 -32767 32767 0 R/W
Ramp ref 1 [SPD] 44 I16 -32767 32767 0 R/W
Ramp ref 2 [SPD] 48 I16 -32767 32767 0 R/W
Control word 55 U16 R/W
Status word 56 U16 R
Ramp ref [SPD] 110 I16 -32767 32767 - R
Ramp outp [SPD] 113 I16 -32767 32767 - R
Speed ref [SPD] 118 I16 -32767 32767 - R
Actual spd [SPD] 122 I16 -32767 32767 - R
Adap reference [SPD] 183 I16 -32767 32767 4000 R/W
Enc 1 position [ENC_PLS] * 197 I16 -32767 32767 - R
Enc 2 position [ENC_PLS] * 198 I16 -32767 32767 - R
Enc 1 last time [ENC_TIM] * 204 U32 0 2 32-1 - R
Enc 1 last time high [ENC_TIM] * 205 U16 0 65535 - R
Enc 2 last time {ENC_TIM] * 206 U32 0 2 32-1 - R
Enc 2 last time high {ENC_TIM] * 207 U16 0 65535 - R
Speed reg output [CURR] 236 I16 -2 * TOP_CURR +2 * TOP_CURR - R
Lock speed reg 322 U16 0 1 0 R/W
Enc 2 speed [SPD] * 420 I16 -37767 32767 - R
Enc 1 speed [SPD] * 427 I16 -37767 32767 - R
Flux current max 467 U16 819 16384 16384 R/W
Flux reference 500 U16 0 16384 16384 R
Pad 0 503 I16 -32768 32767 0 R/W
Pad 1 504 I16 -32768 32767 0 R/W
Pad 2 505 I16 -32768 32767 0 R/W
Pad 3 506 I16 -32768 32767 0 R/W
Pad 4 507 I16 -32768 32767 0 R/W
Pad 5 508 I16 -32768 32767 0 R/W
Pad 6 509 I16 -32768 32767 0 R/W
Pad 7 510 I16 -32768 32767 0 R/W
Pad 8 511 I16 -32768 32767 0 R/W
Pad 9 512 I16 -32768 32767 0 R/W
Pad 10 513 I16 -32768 32767 0 R/W
Pad 11 514 I16 -32768 32767 0 R/W
Pad 12 515 I16 -32768 32767 0 R/W
Pad 13 516 I16 -32768 32767 0 R/W
Pad 14 517 I16 -32768 32767 0 R/W
Pad 15 518 I16 -32768 32767 0 R/W
