——— FUNCTION DESCRIPTION ———
6
217
6.18.3 Speed limitation
DRIVECOM
Speed amount
[1] Speed min amount [FF]
[2] Speed max amount [FF]
Speed min/max
[5] Speed min pos [FF]
[3] Speed max pos [FF]
[6] Speed min neg [FF]
[4] Speed max neg [FF]
Parameter description No.
Value
Standard
Configuration min max
Factory
American
Factory
European
Speed min amount [FF] 1 0 2 32-1 0 0 -
Speed max amount [FF] 2 0 2 32-1 5000 5000 -
Speed min pos [FF] 5 0 2 32-1 0 0 -
Speed max pos [FF] 3 0 2 32-1 5000 5000 -
Speed min neg [FF] 6 0 2 32-1 0 0 -
Speed max neg [FF] 4 0 2 32-1 5000 5000 -
Speed min amount Defines the minimum speed for both rotation directions (with 6KDV3 ... Q4...).
A lower value than the defined value is not possible, regardless of the reference value
set. It has an effect on the input of the ramp. If the Speed min amount parameter is
changed, the Speed min pos and Speed min neg parameters are set to the same value.
If one of these two parameters is changed later, the last change is valid. The current
value for positive rotation (clockwise) is shown in the display of the keypad. The value
to be entered is based on the factor function.
Speed max amount Defines the maximum speed for both rotation directions (with 6KDV3 ... Q4...).
The function has an effect on the input of the speed regulator and therefore takes into
account the reference value that comes from the ramp as well as the directly defined
values (see Figure 6.4.2.1). If the Speed max amount is changed, the Speed max pos
and Speed max neg parameters are set to the same value. If one of these two param-
eters is changed later, the last change is valid. The current value for positive rotation
(clockwise) is shown in the display of the keypad. The value to be entered is based on
the factor function.
Speed min pos Defines the minimum speed for the clockwise rotation of the motor. A lower value than
the defined value is not possible, regardless of the reference value. The function has an
effect on the input of the ramp (see Figure 6.4.1.1). The value to be entered is based on
the factor function.
Speed max pos Defines the maximum speed for the clockwise rotation of the motor. The function has
an effect on the input of the speed regulator, and therefore takes into consideration the
reference value that comes from the ramp as well as those that are entered directly (see
Figure 6.4.2.1). The value to be entered is based on the factor function.
