GEI-100332Ga
——— PARAMETER LISTS ———
10
46
Parameter No. Format
Value Access via
min max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
Jog reference [FF] 266 I16 0 32767 0 0 ü R/W IA -
Motor nom flux
(Motor field curr [A])
280 Float 0.0 P374 P374 P374 ü R/Z - -
Forward sign 293 U16 0 1 0 0 - R/W ID R/W
Reverse sign 294 U16 0 1 0 0 - R/W ID R/W
An in 1 target
Assigned
Not assigned
295 U16 0 1 0 0 ü R/W
0
1
ID
L
H
R/W
0
1
An in 2 target
Assigned
Not assigned
296 U16 0 1 0 0 ü R/W
0
1
ID
L
H
R/W
0
1
An in 3 target
Assigned
Not assigned
297 U16 0 1 0 0 ü R/W
0
1
ID
L
H
R/W
0
1
Drive type
DV-300...Q2
DV-300...Q4
300 U16 10 11 S S - R
10
11
- R
10
11
Enable overload
Enabled
Disabled
309 I16 0 1 Enabled Disabled ü R/Z
1
0
- -
Overload time [s] 310 U16 0 65535 60 30 ü R/W - -
Pause time [s] 311 U16 0 65535 540 300 ü R/W - -
Overload current [%] 312 U16 P313 200 150 100 ü R/W - -
Base current [%] 313 U16 0 P312
< 100
100 80 ü R/W - -
Enable drive
Enabled
Disabled
314 U16 0 1 Disabled Disabled ü R/W
1
0
12
H
L
R/W
1
0
Start/Stop
Start
Stop
315 U16 0 1 Stop
(0)
Stop
(0)
R/W
1
0
13
H
L
R/W
1
0
Fast stop
Fast Stop
No Fast Stop
316 U16 0 1 No Fast
Stop
No Fast
Stop
- R/W
0
1
14
L
H
R/W
0
1
Overload mode
Curr limited
Curr not limited
I2t Motor
I2t Drive
I2t Motor & Drv
318 U16 0 4 I2t Motor Curr
limited
ü R/W
0
1
2
3
4
- -
Device address 319 U16 0 127 0 0 ü R/Z - -
Lock speed reg
ON
OFF
322 U16 0 1 OFF OFF ü R/W
1
0
ID
L
H
R/W
1
0
Ser protocol sel
SLINK3
MODBUS RTU
JBUS
323 U16 0 2 SLINK3
(0)
SLINK3
(0)
ü R/W
0
1
2
-- ---
Ser baudrate sel
19200
9600
4800
2400
1200
326 U16 0 4 9600
(1)
9600
(1)
ü R/W
0
1
2
3
4
-- ---
Failure text 327 Text - R - -
Failure hour 328 U16 0 65535 R - -
Failure minute 329 U16 0 59 R - -
