Table 4.3.3: cable section for ul approval – GE Industrial Solutions DV-300 DC Drive Users Manual User Manual
Page 47
DV-300 Adjustable Speed Drives
——— WIRING PROCEDURES ———
4
3
Table 4.3.3: Cable section for UL approval
Device type
Terminals
Wire
AWG / kcmils
Terminal bolt
metric size [mm]
Tightening
torque [Nm]
6KDV3017...
U, V, W
10
5
6
C, D
10
5
6
PE
10
5
6
6KDV3035...
U, V, W
8
5
6
C, D
8
5
6
PE
8
5
6
6KDV3056...
U, V, W
4
5
6
C, D
4
5
6
PE
4
5
6
6KDV3088...
U, V, W
1/0
terminal block
12
C, D
1/0
terminal block
12
PE
2
terminal block
12
6KDV3112...
U, V, W
2/0
terminal block
12
C, D
2/0
terminal block
12
PE
2
terminal block
12
6KDV3148...
U, V, W
3/0
terminal block
12
C, D
4/0; kit required
terminal block
12
PE
2
terminal block
12
6KDV3224...
U, V, W
2 x 2/0
10
50
C, D
2 x 2/0
10
50
PE
2/0
8
25
6KDV3280...
U, V, W
2 x 4/0
10
50
C, D
2 x 4/0
10
50
PE
2/0
8
25
6KDV3336...
U, V, W
2 x 4/0
10
50
C, D
2 x 300
10
50
PE
2/0
8
25
6KDV3400...
U, V, W
2 x 300; kit required
10
50
C, D
2 x 350; kit required
10
50
PE
2/0
8
25
6KDV3450...
U, V, W
2 x 500; kit required
10
50
C, D
2 x 600; kit required
10
50
PE
2/0
8
25
6KDV3560...
U, V, W
4 x 4/0
10
50
C, D
4 x 250
10
50
PE
2/0
8
25
6KDV3800...
U, V, W
4 x 300; kit required
10
50
C, D
4 x 350; kit required
10
50
PE
2/0
8
25
6KDV3850...
U, V, W
4 x 300; kit required
10
50
C, D
4 x 400; kit required
10
50
PE
2/0
8
25
DV0121g
The following sizes are not provided with pressure connectors.
Any UL listed lug, sized for the indicated bolt and AWG cable, is suitable for use.
Compression lug from ILSCO manufacturer are suggested for sizes greater than 56A.
