Table 4.6.1.1: terminal strip connections – GE Industrial Solutions DV-300 DC Drive Users Manual User Manual
Page 58
GEI-100332Ga
——— WIRING PROCEDURES ———
4
14
4.6.1 Assignment of the plug-in terminal strip (terminals 1...15) for Option Card 6KCV300TBO
Table 4.6.1.1: Terminal strip connections
Designation
Function
I/O
Max
voltage
Max
current
1
Analog output 1
(3)
Analog output 1 (3)
Reference point: Terminal 2
Factory set for T current (motor current)
O
±10V
5mA
2
COM analog
output 1
Reference point of analog output 1 (Terminal 1)
—
—
—
3
Analog output 2
(4)
Analog output 2 (4)
Reference point: Terminal 4
Factory set for motor speed ( Current U)
O
±10V
5mA
4
COM analog
output 2
Reference of analog output 2 (Terminal 3)
—
—
—
5
COM digital
outputs
COM digital outputs (Terminals 6...9)
—
—
—
6
Digital output
1 (5)
Digital output 1 (5)
COM: Terminal 5
Factory set for Ramp + (Curr limit state)
O
+30V
50mA
7
Digital output
2 (6)
Digital output 2 (6)
COM: Terminal 5
Factory set for Ramp - (Overvoltage)
O
+30V
50mA
8
Digital output
3 (7)
Digital output 3 (7)
COM: Terminal 5
Factory set for Spd threshold (Undervoltage)
O
+30V
50mA
9
Digital output
4 (8)
Digital output 4 (8)
COM: Terminal 5
Factory set for Overload available (Overcurrent)
O
+30V
50mA
10
Supply digital
outputs
Supply voltage for digital outputs
I
+30V
depends on
the load
max 80mA
11
Digital input
1 (5)
Digital input 1 (5)
COM: Terminal 15
Not Factory set
I
+30V
15V/3.2mA
24V/5mA
30V/6.4mA
12
Digital input
2 (6)
Digital input 2 (6)
COM: Terminal 15
Not Factory set
I
+30V
15V/3.2mA
24V/5mA
30V/6.4mA
13
Digital input
3 (7)
Digital input 3 (7)
COM: Terminal 15
Not Factory set
I
+30V
15V/3.2mA
24V/5mA
30V/6.4mA
14
Digital input
4 (8)
Digital input 4 (8)
COM: Terminal 15
Not Factory set
I
+30V
15V/3.2mA
24V/5mA
30V/6.4mA
15
COM digital
inputs
COM of the digital inputs (Terminals 11...14)
—
—
GD0240g
