DV-300 Adjustable Speed Drives
——— PARAMETER LISTS ———
10
27
Parameter No. Format
Value Access via
min max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
FUNCTIONS \ Multi ramp fct \ Ramp 0 \ Acceleration 0
Acc delta speed0 [FF] 659 U32 0 232-1 100 100 ü R/W - -
Acc delta time 0 [s] 660 U16 0 65535 1 1 ü R/W - -
S acc t const 0 [ms] 665 Float 100 3000 300 300 ü R/W - -
FUNCTIONS \ Multi ramp fct \ Ramp 0 \ Deceleration 0
Dec delta speed0 [FF] 661 U32 0 232-1 100 100 ü R/W - -
Dec delta time 0 [s] 662 U16 0 65535 1 1 ü R/W - -
S dec t const 0 [ms] 666 Float 100 3000 300 300 ü R/W - -
FUNCTIONS \ Multi ramp fct \ Ramp 1 \ Acceleration 1
Acc delta speed1 [FF] 23 U32 0 232-1 100 100 ü R/W - -
Acc delta time 1 [s] 24 U16 0 65535 1 1 ü R/W - -
S acc t const 1 [ms] 667 Float 100 3000 300 300 ü R/W - -
FUNCTIONS \ Multi ramp fct \ Ramp 1 \ Deceleration 1
Dec delta speed1 [FF] 31 U32 0 232-1 100 100 ü R/W - -
Dec delta time 1 [s] 32 U16 0 65535 1 1 ü R/W - -
S dec t const 1 [ms] 668 Float 100 3000 300 300 ü R/W - -
FUNCTIONS \ Multi ramp fct \ Ramp 2 \ Acceleration 2
Acc delta speed2 [FF] 25 U32 0 232-1 100 100 ü R/W - -
Acc delta time 2 [s] 26 U16 0 65535 1 1 ü R/W - -
S acc t const 2 [ms] 669 Float 100 3000 300 300 ü R/W - -
FUNCTIONS \ Multi ramp fct \ Ramp 2 \ Deceleration 2
Dec delta speed2 [FF] 33 U32 0 232-1 100 100 ü R/W - -
Dec delta time 2 [s] 34 U16 0 65535 1 1 ü R/W - -
S dec t const 2 [ms] 670 Float 100 3000 300 300 ü R/W - -
FUNCTIONS \ Multi ramp fct \ Ramp 3 \ Acceleration 3
Acc delta speed3 [FF] 27 U32 0 232-1 100 100 ü R/W - -
Acc delta time 3 [s] 28 U16 0 65535 1 1 ü R/W - -
S acc t const 3 [ms] 671 Float 100 3000 300 300 ü R/W - -
FUNCTIONS \ Multi ramp fct \ Ramp 3 \ Deceleration 3
Dec delta speed3 [FF] 35 U32 0 232-1 100 100 ü R/W - -
Dec delta time 3 [s] 36 U16 0 65535 1 1 ü R/W - -
S dec t const 3 [ms] 672 Float 100 3000 300 300 ü R/W - -
Ramp sel 0
Value 2 0 not selected
Value 2 0 selected
403 U16 0 1 0 0 - R/W
0
1
ID
L
H
R/W
0
1
Ramp sel 1
Value 2 1 not selected
Value 2 1 selected
404 U16 0 1 0 0 - R/W
0
1
ID
L
H
R/W
0
1
FUNCTIONS \ Speed draw
Speed ratio 1017 I16 0 +32767 +10000 +10000 ü R/W IA R/W
Speed draw out (d) 1018 I16 -32768 +32767 - - ü R QA R/W
Speed draw out (%) 1019 Float -200.0 +200.0 - - ü R - -
FUNCTIONS \ Overload contr
Enable overload
Enabled
Disabled
309 I16 0 1 Enabled Disabled ü R/Z
1
0
- -
Overload mode
Curr limited
Curr not limited
I2t Motor
I2t Drive
I2t Motor & Drv
318 U16 0 4 I 2 t Motor Curr
limited
ü R/W
0
1
2
3
4
- -
Overload current [%] 312 U16 P313 200 150 100 ü R/W - -
