GEI-100332Ga
——— CONVERTER OPERATION ———
5
10
Changing rotation direction
Motor pot
Motor pot sign
-
+
Clockwise
(positive)
Anti-clockwise
(negative)
ENT
Motor pot sign
positive
ENT
- Select the Motor pot sign parameter in the “Motor pot” submenu.
- Pressing ENT the current rotation direction is displayed.
- Press the + key to select clockwise rotation and the - key for counterclockwise rotation.
- Confirm by pressing ENT.
- Changing the Motor pot sign parameter during operation causes the drive to reverse rotation according to
the ramp times set.
Resetting the speed reference value
Motor pot
Motor pot reset
ENT
Reference value = 0
- Select the Motor pot reset parameter in the “Motor pot” submenu.
- Press ENT. The reference speed is set to zero.
n
ote
! The speed reference value can only be reset when the drive is switched off.
5.1.5.4. Jog function
n
ote
! The Jog function must be enabled via the Enable jog parameter!
Jog function
Jog operation
-
+
Jog forward
(clockwise)
Jog backward
(anti-clockwise)
CANC
ENT
Jog operation
137 [rpm]
- Select the Jog operation parameter in the “Jog function” submenu.
- Press ENT. The selection Jog function is displayed.
- Press the + key to select clockwise rotation and the - key for counterclockwise rotation.
- Press CANC to return to the “Jog function” submenu.
