DV-300 Adjustable Speed Drives
——— FUNCTION DESCRIPTION ———
6
215
6.18 DRIVECOM
The DRIVECOM profile #21 “Power transmission,” defines the behavior of the drive if this is operated via the INTER-
BUS-S field bus. The DRIVECOM menu of the DV-300 converter provides functions that were defined in the
above standards and which are required to operate a motor with the converter. The DV-300 converters, however,
have a considerably greater range of functions than is defined here. Apart from a few exceptions the parameters
provided in this menu are described somewhere else in detail. We will therefore restrict this description to the
Parameters function. See section 10, “Parameter list” and the above standard for further information on the
parameters. When operating from a Bus, the parameters in the Drivecom group can also be accessed using the
format and index specified in the above standard.
6.18.1 Control word, status word, malfunction code
DRIVECOM
[57] Malfunction code
[55] Control word
[56] Status word
Parameter description No.
Value
Standard
Configuration min max
Factory
American
Factory
European
Malfunction code 57
Control word 55 0 65535
Status word 56 0 65535
Malfunction code Malfunction code according to DRIVECOM specification (Mandatory functions)
The code displayed indicates a particular failure. The meaning of the individual failures
concerned is described in the section Programmable Alarms.
0000h No failure
1001h Unknown
2300h Overcurrent
3120h Undervoltage
3310h Overvoltage
3330h Field loss
4210h Heatsink
4310h Overtemp motor
5000h Hardware
5100h Failure supply
6110h Dsp error
6120h Interrupt error
7301h Speed fbk loss
7400h Opt2
7510h Hw Opt 1 failure
8110h Bus loss
9000h External fault
9009h Enable seq err
The code and the alarm are displayed in plain text in the event of a failure. The code is
given in hexadecimal format.
Control word Control word according to DRIVECOM specification (Mandatory functions)
Status word Status word according to DRIVECOM specification (Mandatory functions).
