DV-300 Adjustable Speed Drives
——— CONVERTER OPERATION ———
5
5
parameters Saving
The parameters must be saved, otherwise the previous values will be loaded the next time the device is switched on.
ENT
START UP
Save parameters
Save parameters
Wait...
Write ok
- Select Save parameters in the START UP or in the SPEC FUNCTIONS menu.
- Press ENT
- The saving operation is automatic. The messages “Wait ...” and “Write ok” will appear in succession before
the original parameter is shown.
Entering a password
The operator can define a password consisting of a freely selectable five-digit number combination in order to
protect the keypad from unauthorized access. This is carried out via the Pword 1 parameter.
ENT
CONFIGURATION
Pword 1: Disabled
Pword 1: Disabled
Password 0 0 0 0 0
+
-
CANC
ENT
ok
Return without changes
0 ... 9
9 ... 0
CONFIGURATION
Pword 1: Enabled
Pword 1: Enabled
Password 0 0 0 0 0
- Select Pword1 (= Password 1) in the CONFIGURATION menu.
- Press ENT. The value 00000 will appear with the last digit flashing. The value of the flashing digit is
changed.
- Increase the numerical value with +
- Reduce the numerical value with -
- Select the next digit left with
- Select the next digit right with
- Confirm the password by pressing ENT. The message: Pword1: Enabled will then appear shortly with the
currently valid password displayed.
- The existing password is indicated in the CONFIGURATION menu via the “Pword 1: Enabled” message.
- Press the CANC key in order to abort the entry of the password.
n
ote
! The password must be saved with Save parameters so that it is also active the next time the
device is switched on.
