GE Industrial Solutions DV-300 DC Drive Users Manual - Manual (Page 442)

GEI-100332Ga
——— PARAMETER LISTS ———
10
48
Parameter No. Format
Value Access via
min max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
Ok relay open
ON
OFF
362 I16 0 1 ON ON ü R/W
1
0
- -
Latch
ON
OFF
363 U16 0 1 ON ON ü R/Z
1
0
- -
Ok relay open
ON
OFF
364 I16 0 1 ON ON ü R/W
1
0
- -
Activity
Ignore
Warning
Disable drive
Quick stop
Normal stop
Curr lim stop
365 U16 Disable
dive
Disable
dive
ü R/Z
0
1
2
3
4
5
- -
Ok relay open
ON
OFF
367 I16 ON ON ü R/W
1
0
- -
Activity
Warning
Disable drive
Quick stop
Normal stop
Curr lim stop
368 U16 1 5 Disable
drive
Disable
drive
ü R/Z
1
2
3
4
5
- -
Ok relay open
ON
OFF
370 I16 0 1 ON ON ü R/W
1
0
- -
Speed limited
Speed not limited
Speed limited
372 U16 0 1 - R
0
1
QD
L
H
R
0
1
Freeze ramp
Active
Not active
373 U16 0 1 Not active
(1)
Not active
(1)
ü R/W
0
1
ID
H
L
R/W
1
0
“Nom flux curr [A]
(Field curr scale [A)]”
374 Float 0.5 70.0 S S ü R/Z - -
Jog selection
Speed input
Ramp input
375 U16 0 1 0 0 ü R/Z
0
1
- -
Speed ref 1 (%) 378 Float -200.0 +200.0 0 0 ü R/W - -
Speed Ref 2 (%) 379 Float -200.0 +200.0 0 0 ü R/W - -
Drive ready
Drive ready
Drive not ready
380 U16 0 1 - - - R
1
0
QD
H
L
R
1
0
Activity
Warning
Disable drive
Quick stop
Normal stop
Curr lim stop
386 U16 1 5 Disable
drive
Disable
drive
ü R/Z
1
2
3
4
5
- -
Ok relay open
ON
OFF
387 I16 0 1 ON ON ü R/W
1
0
- -
Auto capture
ON
OFF
388 U16 OFF
(0)
OFF
(0)
ü R/W
1
0
ID
H
L
-
Input 1 sign
Positive
Negative
389 U16 0 1 1 1 ü R/W
1
0
- R/W
1
0
