SCSI Registers
4-47
Version 2.2
Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.
R
Reserved
4
SPL1
Latched SCSI Parity for SD[15:8]
3
This active HIGH bit reflects the SCSI odd parity signal
corresponding to the data latched into the most significant
byte in the
register.
R
Reserved
2
LDSC
Last Disconnect
1
This bit is used in conjunction with the Connected (CON)
bit in
. It allows the user to
detect the case in which a target device disconnects, and
then a SCSI device selects or reselects the
LSI53C1010R SCSI function. If the Connected bit and
the LDSC bit are asserted, a disconnect is indicated. This
bit is set when the Connected bit in SCNTL1 is off. This
bit is cleared when a Block Move instruction is executed
while the Connected bit in SCNTL1 is set.
SDP1
SCSI SDP1 Parity Signal
0
This bit represents the present state of the SCSI SDP1/
parity signal. It is not latched and may change as it is read.
Registers: 0x10–0x13
Data Structure Address (DSA)
Read/Write
DSA
Data Structure Address
[31:0]
This 32-bit register contains the base address used for all
Table Indirect calculations. The DSA register is usually
loaded prior to starting an I/O, but it is possible for a
SCRIPTS Memory Move to load the DSA during the I/O.
During any Memory-to-Memory Moves operation, the
contents of this register are preserved. The power-up
value of this register is indeterminate.
31
