4.1 General Specifications
— 4-3 —
4.1 General Specifications
This section provides the general specifications of the GL120 and GL130.
The general specifications of the GL120 and GL130 are shown in the following table.
Table 4.1 General Specifications
Item Specifications
Dielectric Strength 1) Between the primary side and the grounding or
between the primary side and the secondary side:
Detected current 10 mA max. with 1,500 VAC for 1
minute or 1,800 VAC for 1 s.
2) Between the secondary side and the grounding:
Detected current 30 mA max. with 500 VAC for 1
minute or 550 VAC for 1 s.
Insulation Resistance 1) 10 MΩ min. between the primary side and the
grounding or between the primary side and the
secondary side (via the 500-VDC insulation
resistance meter)
2) 100 MΩ min. between the secondary side and the
grounding (via the 500-VDC insulation resistance
meter)
Environment
Conditions
Ambient Operating
Temperature
0 to 60 _C
Co d o s
Ambient Storage
Temperature
−25 to 85 _C (except batteries)
Ambient Operating
Humidity
30% to 95% RH (with no condensation)
Ambient Storage
Humidity
5% to 95% RH (with no condensation)
Pollution Level Pollution level 1 according to JIS B 3501
Corrosive Gas No corrosive gas
Operating Altitude Less than 2,000 m above sea level
Mechanical
Operating
Conditions
Vibration Resistance 10 to 57 Hz with half-amplitude of 0.075 mm
57 to 150 Hz with fixed acceleration of 9.8 m/s 2
10 sweep times each in X, Y, and Z directions
(according to JIS B 3502)/(sweep time: 1 octave/min)
Shock Resistance Peak acceleration of 147 m/s 2 twice for 11 ms in X, Y,
and Z directions (according to JIS B 3502)
Electrical
Operating
Conditions
Noise Resistance 1,500 V in either normal or common mode with pulse
widths of 100 ns/1 µs and rise time of 1 ns
(according to JIS B 3502) (with impulse noise simulator)
Installation
R i
Ground Ground to 100 Ω or less
Require-
ments
Configuration Building-block, wall-mounted or DIN track-mounted
ments
Cooling Method Natural cooling
