Low Voltage Directives
6.2.4 Specifications of the I/O Module
— 6-16 —
6.2.4 Specifications of the I/O Module
The following table shows the specifications of the I/O Module conforming to the Low Voltage
Directive.
1) 100-to 120-VAC 16-point Input Module
Table 6.4 Specifications of the 100-to 120-VAC 16-point Input Module
Item Specification
Name 100- to 120-VAC 16-point Input Module
Model Name AC100IN-16P
Model No. JAMSC-120DAI54309 (EN standards)
Rated Voltage 100 to 120 VAC
Maximum Allowable Voltage 132 VAC
Rated Frequency 50/60 Hz
Allowable Frequency Range 47 to 63 Hz
Inrush Current 160 mA
Rated Current 7 mA (at 100 VAC, 50 Hz)
Input Impedance 14.3 kΩ (at 100 VAC, 50 Hz)
12.5 kΩ (at 100 VAC, 60 Hz)
Standard Operating Ranges ON voltage range: 74 to 132 VAC
OFF voltage range: 30 VAC max.
Input Type AC type 2 (according to IEC1131-2)
Input Delay Times OFF to ON: 20 ms max.
ON to OFF: 35 ms max.
Number of Commons 2
Number of Inputs per Common 8 points/common
Input Power Supply per Common Different power supply phases cannot be connected for
each common.
External Connections Removable terminal block with M3 Phillips screw terminals
Number of Inputs 16
Input Signal Indication Indicator for each point; lit when input is ON.
Status saved in internal logic.
Status Indication ACTIVE: Lits during input processing
Insulation Method Photocoupler
Dielectric Strength 1,500 VAC for 1 min or 1,800 VAC for 1 s between input
terminals and ground (via 500-VDC insulation resistance
meter)
Insulation Resistance 100 MΩ min. at room temperature and humidity between
input terminals and ground (via 500-VDC insulation
resistance meter)
External Power Supply 100 to 120 VAC supplied to signals
Derating Conditions None
Internal Current Consumption 90 mA max. at 5 VDC (with all points ON)
Maximum Heating Value 2.0 W
Hot Swapping (Removal/Insertion
under Power)
Permitted
Approximate Mass 250 g
External Dimensions 40.3 x 130 x 103.9 mm (W x H x D)
