w w w . d i g i e m b e d d e d . c o m 7 6 5
U S B C o n t r o l l e r M o d u l e
USB Device Block registers
Table 445 provides the addresses of the USB Device Block registers.
Device Descriptor/Setup Command register
Address: 9010 2000
The Device Descriptor/Setup Command register is a legacy register. This register
must be written to the value
0x0000_0100
.
Address Register
9010 2000 Device Descriptor/Setup Command register
9010 2004 Endpoint Descriptor #0
9010 2008 Endpoint Descriptor #1
9010 200C Endpoint Descriptor #2
9010 2010 Endpoint Descriptor #3
9010 2014 Endpoint Descriptor #4
9010 2018 Endpoint Descriptor #5
9010 201C Endpoint Descriptor #6
9010 2020 Endpoint Descriptor #7
9010 2024 Endpoint Descriptor #8
9010 2028 Endpoint Descriptor #9
9010 202C Endpoint Descriptor #10
9010 2030 Endpoint Descriptor #11
Table 445: USB Device Block registers address map
