N S 9 7 5 0 P i n o u t
Reserved
Pin# Description
J1 Tie to ground directly
K3 Tie to ground directly
K2 Tie to ground directly
K1 Tie to ground directly
R1 Tie to ground directly
R2 Tie to ground directly
R3 Tie to ground directly
T1 Tie to ground directly
AF6 Tie to ground directly
AE3 Tie to ground directly
AC5 Tie to ground directly
AD4 Tie to 1.5V core power
AF2 Tie to 3.3V I/O power
AE7 No connect
L3 No connect
L2 No connect
L1 No connect
M3 No connect
M2 Tie to ground directly
M1 Tie to ground directly
N1 Tie to ground directly
N2 Tie to ground directly
AF22 No connect
AD21 No connect
AE22 No connect
Table 15: Reserved pins
