L C D C o n t r o l l e r
Signal polarity, active high or low
AC panel bias
Panel clock frequency
Bits-per-pixel
Display type, STN mono/color or TFT
STN 4- or 8-bit interface mode
STN dual- or single-panel mode
Little endian, big endian, or WinCE mode
Interrupt generation event
LCD panel resolution
The LCD can be programmed to support a wide range of panel resolutions, including
but not limited to:
320 x 200, 320 x 240
640 x 200, 640 x 240, 640 x 480
800 x 600
1024 x 768
LCD panel support
The LCD controller supports these types of panels:
Active matrix TFT panels with up to 24-bit bus interface
Single-panel monochrome STN panels (4-bit and 8-bit bus interface)
Dual-panel monochrome STN panels (4-bit and 8-bit bus interface per panel)
Single-panel color STN panels, 8-bit bus interface
Dual-panel color STN panels, 8-bit bus interface per panel
