S y s t e m C o n t r o l M o d u l e
Register bit assignment
BIts Access Mnemonic Reset Definition
D07 R/W IE 0x0 Interrupt enable
0 Interrupt is disabled
1 Interrupt is enabled
D06 R INV 0x0 Invert
0 Do not invert the level of the interrupt source.
1 Invert the level of the interrupt source.
D05 R/W IT 0x0 Interrupt type
0 IRQ
1 FIQ
D04:00 R/W ISD 0x0–
0x1F Interrupt source ID
Assign an interrupt ID to each priority level. See
"Interrupt sources," beginning on page 268, for the list of
interrupt ID numbers.
Table 178: Int Config register
Interrupt source ID
13 12 11 10 9 8 7 6 5 4 3 2 1 0 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
IE INV IT
Int Config registers 0, 4, 8, 12, 16,
20, 24, 28
Int Config registers 1, 5, 9, 13, 17,
21, 25, 29
Int Config registers 2, 6, 10, 14, 18,
22, 26, 30
Int Config registers 3, 7, 11, 15, 19, 23, 27, 31
