I E E E 1 2 8 4 P e r i p h e r a l C o n t r o l l e r
Forward Address register
Address: 9040 0174
The Forward Address register is updated when a channel address command is
received during a forward ECP transfer.
Register bit assignment
Bits
Access
Mnemonic
Reset
Description
D31:08
R
Reserved
0
N/A
D07:00
R
eca
0
Forward address.
Table 412: eca — Forward Address register
eca
13
12
11
10
9
8
7
6
5
4
3
2
1
0
15
14
31
29
28
27
26
25
24
23
22
21
20
19
18
17
16
30
Reserved
Reserved
