R e g i s t e r s

5 8 2

N S 9 7 5 0 H a r d w a r e R e f e r e n c e

LCDTiming1

Address: A080 0004

The LCDTiming1 register controls the vertical axis panel, which includes:

Number of lines-per-panel (LPP)

Vertical synchronization pulse width (VSW)

Vertical front porch (VFP) period

Vertical back porch (VBP period)

Register bit assignment

Bits

Access

Mnemonic

Reset

Description

D31:24

R/W

VBP

0x00

Vertical back porch

Number of inactive lines at the start of a frame, after
vertical synchronization period. Program this field to
zero on passive displays, to avoid reduced contrast.

VBP specifies the number of line clocks inserted at
the beginning of each frame. The VBP count starts
just after the

CLFP

for the previous frame has been

negated for active mode, or the extra horizontal
synchronization lines have been asserted as specified
by the VSW field in passive mode. After this occurs,
the count value in VBP sets the number of horizontal
synchronization lines inserted before the next frame.
VBP generates from
0 –255 extra line clock cycles.

Table 352: LCDTiming1 register

VBP

LPP

VSW

VFP
