S y s t e m c o n f i g u r a t i o n r e g i s t e r s
2 9 0
N S 9 7 5 0 H a r d w a r e R e f e r e n c e
Interrupt Status Raw
Address: A090 016C
The Interrupt Status Raw register shows all current interrupt requests.
Register bit assignment
Bits
Access
Mnemonic
Reset
Description
D31:00
R
ISRAW
0x0
Interrupt status raw
Provides the status of all active, enabled, and disabled
interrupt request levels, where bit 0 is for the interrupt
assigned to level 0, bit 1 is for the interrupt assigned to
level 1, and so on through bit 31 for the interrupt assigned
to level 31.
Table 181: Interrupt Status Raw register
13
12
11
10
9
8
7
6
5
4
3
2
1
0
15
14
31
29
28
27
26
25
24
23
22
21
20
19
18
17
16
30
Interrupt status raw (ISRAW)
Interrupt status raw (ISRAW)
