w w w . d i g i e m b e d d e d . c o m 6 4 7
S e r i a l C o n t r o l M o d u l e : S P I
FIFO management
Data flow between a serial controller and memory occurs through the FIFO blocks
within each serial controller module. Each serial controller provides both a 32-byte
transmit FIFO and a 32-byte receive FIFO. Each FIFO is arranged as eight lines of four
bytes to facilitate data transfer across BBus. Both the transmit and receive FIFOs are
accessed using the Serial Channel B/A/C/D FIFO registers.
Transmit FIFO interface
The processor can write either 1, 2, 3, or 4 bytes at a time to the transmit FIFO. The
number of bytes written is controlled by the data size defined by the
HSIZE
field on
the AMBA AHB bus.
When the system is configured to operate in big endian mode, the most
significant bytes in the word written to the FIFO are transmitted first. For
example, the long word
0x11223344
results in the character
0x11
being
transmitted first, and
0x44
being transmitted last.
When the system is configured to operate in little endian mode, the least
significant bytes in the word written to the FIFO are transmitted first. For
example, the long word
0x11223344
results in the character
0x44
being
transmitted first, and
0x11
being transmitted last.
Serial channel B/A/C/D bit rate
register settings
Mode functionality
SPI
mode
SPCPOL TXCINV RXCINV
SPI CLK
Idle SPI DATA_IN
capture edge SPI DATA-OUT
drive edge
0 1 0 0 Low Rising Falling
1 0 1 1 High Falling Rising
2 1 1 1 Low Falling Rising
3 0 0 0 High Rising Falling
Table 381: SPI mode definitions
