S e r i a l p o r t c o n t r o l a n d s t a t u s r e g i s t e r s
6 1 8 N S 9 7 5 0 H a r d w a r e R e f e r e n c e
Bits Access Mnemonic Reset Description
D31:28 R MATCH 0x0 Match bit
[31] Match1
[30] Match2
[29] Match3
[28] Match4
Set when a match character in the Receive Match register
is configured at the same time that the enable receive data
match bit is set in Serial Channel Control Register B (see
"RDM" on page 616). The match bit indicates that a data
match was found in the receive data stream, and the
current receive data buffer has been closed. The last
character in the receive data buffer contains the actual
match character found.
In DMA mode, the MATCH field is copied to bits [15:12]
in the DMA buffer descriptor.
D27 R BGAP 0 Buffer GAP timer
Set when the receive buffer GAP timer is set in Serial
Channel Control Register B (see "RBGT" on page 616)
and the timeout value defined in the Receive Buffer GAP
Timer register has expired. This bit indicates that the
maximum allowed time has passed since the first byte was
placed into the receive data buffer. The receive data buffer
is closed under this condition.
In DMA mode, this field is copied to bit [11] in the DMA
buffer descriptor.
Table 369: Serial Channel B/A/C/D Status Register A
CTSI
T
EMPTY
13 12 11 10 9 8 7 6 5 4 3 2 1 0 15 14
31 29 28 27 26 25 24 23 22 21 20 19 18 17 16 30
CGAP BGAP RXFDB DCD
Match
Not used
RBRK DSRI THALF
1 2 3 4
RI DSR CTS
RFE RPE ROVER RRDY RHALF RBC RFS DCDI RII TRDY
Not
used
