3 0 1
S y s t e m C o n t r o l M o d u l e
Active Interrupt Level Status register
Address: A090 018C
The Active Interrupt Level Status register shows the current active interrupt level.
Register bit assignment
Timer 0–15 Control registers
Address: A090 0190 / 0194 / 0198 / 019C / 01A0 / 01A4 / 01A8 / 01AC / 01B0 / 01B4 / 01B8 /
01BC / 01C0 / 01C4 / 01C8 / 01CC
Use the Timer Control registers to select the source clock frequency, as well as other
attributes, for each general purpose timer/counter.
Bits
Access
Mnemonic
Reset
Description
D31:06
N/A
Reserved
N/A
N/A
D05:00
R
INTID
0x0
Interrupt
The level of the current active interrupt.
Table 189: Active Interrupt Level Status register
13
12
11
10
9
8
7
6
5
4
3
2
1
0
15
14
31
29
28
27
26
25
24
23
22
21
20
19
18
17
16
30
Reserved
Reserved
INTID
13
12
11
10
9
8
7
6
5
4
3
2
1
0
15
14
31
29
28
27
26
25
24
23
22
21
20
19
18
17
16
30
Reserved
Reserved
TEN
INTC
TLCS
TM
INTS
UDS
TSZ
REN
