App-36
IM 04L31A01-01E
Set mode
#1 Range,alarm
Parameter Initial Value
First-CH 01
Last-CH 01
Range > Mode Volt
Range > Range 2 V
Range > Span Upper –2.000
Range > Span Lower 2.000
Alarm > 1 to 4 Off
#2 Tag,Moving average,Alarm delay
Parameter Initial Value
First-CH 01
Last-CH 01
Tag 01
Moving average > Count Off
Alarm delay Time 10 s
#3 Trend/Save interval,Message,File,User key,DST
Parameter Initial Value
Trend/Save interval > Time/div 1min
Trend/Save interval > Auto save interval 1 h
Message > Characters No. 1 to No. 8 Space
File > Header Space
File > Directory name DATA0
USER key > Action AlarmACK
Daylight saving time (YY/MM/DD HH) > Summer Off
Daylight saving time (YY/MM/DD HH) > Winter Off
Appendix 6 Initial Values
