12-3
IM 04L31A01-01E
12
Troubleshooting
Operation Errors
• Errors Related to the External Storage Medium
Code Message Explanation/Countermeasures/Ref. section
200 Operation aborted because an error was found in media. See the Communication Interface User’s Manual.
201 Not enough free space on media. Use another storage medium.
202 Media is read-only. Release the write protection.
210 Media has not been inserted. Insert a storage medium into the drive.
211 Media is damaged or not formatted. Use another storage medium or carry out
formatting.
212 Format error. Try formatting again or use another storage
medium.
213 The file is read-only. Access another file or write-enable the file.
214 There is no file or directory. See the Communication Interface User’s Manual.
215 Exceeded the allowable number of files. Use another storage medium.
Delete unneeded files.
216 The file or directory name is incorrect. See sections 9.1 and 9.3.
217 Unknown file type. Specify another file.
218 Directory exists. Delete the directory or change directory neme. See section 9.1.
219 Invalid file or directory operation. Tried to delete multiple directory levels.
220 The file is already in use. Try again later. Wait until the file is accessible.
• Errors Related to the Historical Trend
Code Message Explanation/Countermeasures/Ref. section
230 There is no setting file. Specify another file.
231 Abnormal setting exists in file. Specify another file.
232 There is no available data. Appears when displaying historical trends.
Specify another file.
233 The specified historical data do not exist. Appears when switching to historical trend from
information display. See section 8.1.
234 The specified channel is not assigned to the display group. Appears when switching to trend or bar graph
from overview. See section 8.6.
12.1 Messages
