881/882 Video Test Generator User Guide (Rev A.22) 77
4. Choose Cache to browse for a built-in image. The following menu appears on the
generator’s display.
5. Choose Images, and then select the image you want to use.
The image appears and begins shifting in accordance with default settings for both
speed and method of shifting (either repeat or reversed). The following settings appear
on the generator’s display as shown below.
a. Configure image shifting parameters by selecting a parameter using its adjacent
soft key, then adjusting the value by pressing the + or - keys.
Refer to the following table for a description of the parameters used to control image
shifting.
Parameter Action
Line Selects image shifting pattern. This can
be either Reverse or Repeat.
• Reverse moves the image in both
directions in accordance with the
shift parameters.
• Repeat moves the image in only one
direction.
HInc Specifies number of pixels the image
travels in a horizontal direction per time
period.
VInc Specifies number of lines the image
travels in a vertical direction per time
period.
TInc Specifies movement to occur per N
number of frames.
Images Fonts
Tools
>Line Reversed<
HInc: 1
VInc: 1
*TInc: 1 Exit!
