574 Chapter 17 Testing Lipsync
3. Activate the HDMI-H interface on the output port:
a. Press the Interface key to access the list of interfaces. A listing of signal interfaces
appears on the generator’s display as shown below.
b. Choose HDMI-H by pressing the adjacent soft key. The interface is activated and
the port outputs the currently selected image and format.
c. Alternatively, to activate the interface through the command line interface, enter the
following commands:
XVSI 4 // Selects the HDMI-H interface
ALLU // Applies the interface setting to the generator
4. Read the EDID from the display as follows:
a. Press the Sink key. The following information appears on the generator’s display.
b. Press the Options key. The following information appears on the generator’s
display.
c. Choose the EDID Formats item by pressing the adjacent soft key. A + appears next
to EDID Formats, indicating it is enabled.
VGA
HDMI-D CVBS
S-VIDEO
SDI
*
HDMI-H
VGA
HDMI-D CVBS
S-VIDEO
SDI *HDMI-H
Manufacturer:SNY
Product Code:144
Serial#:7011007
Week:20 Year:1998
-EDID Formats CDF
+HP Bypass
-Emulate
