881/882 Video Test Generator User Guide (Rev A.22) 201
Viewing the Content list of images
You can view the list of images available in the generator through the front panel or the
command line interface. Use the following procedure to view the image list using the front
panel.
Note: The list of images that appears on the generator’s display is determined by the
image path. In addition, the list may be filtered based on the image catalogs that are
enabled. For more information about
setting the path, see “
Setting the generator’s path ” on page 18. For more information about
image catalogs, see “ Creating image catalogs ” on page 211.
To view the images in the Content list using the front panel:
Press the Content key. A list of images appears on the generator’s display as shown
below. You can scroll through the list using the + and - keys.
Viewing and modifying image options
Procedures for viewing and modifying the image options through the front panel are
provided below.
To view and modify a format’s options using the front panel:
1. Press the Contents key and choose an image by pressing the adjacent soft key.
a. Press the Options key. The image options appear on the generator’s display as
shown below.
2. Enable or disable the desired option by pressing the adjacent soft key.
Viewing image versions
Many images have secondary or alternate version and some images have many versions.
Use the procedures below to view the alternate and multiple image versions.
Acer1 Acer2
Acer3 Acer4
Acer5 Acer6
Acer7 Acer8
-Alternate
Red+
-NoGamma Green+
-Noise Blue+
