881/882 Video Test Generator User Guide (Rev A.22)
447
To bypass hot plug detection:
If the display under test has not implemented hot plug correctly, you will have to bypass
hot plug detection in the generator to enable video output.
1. Connect the generator to the display you want to test.
2. Press the
Sink key. The following information appears on the generator’s display.
3. Press the
Options key. The following information appears on the generator’s display.
4. Choose the
HP Bypass (hot plug bypass) item by pressing the adjacent soft key. A +
appears next to HP Bypass indicating enabled.
To use Emulate mode:
Emulate mode automatically sets color space, and other settings based on the interface
and format selected:
1. Connect the generator to the display you want to test.
2. Press the
Sink key. The following information appears on the generator’s display.
3. Press the
Options key. The following information appears on the generator’s display.
4. Choose the
Emulate item by pressing the adjacent soft key. A + appears next to
Emulate indicating enabled.
Alternatively, to select the emulate mode through the command line interface, enter the
command shown below:
EMUG 1
// Enables emulate mode
To disable the emulate mode through the command line interface, enter the command
shown below:
Manufacturer:DEL
Product Code:41003
Serial#:7011007
Week:52 Year:2007
-EDID Formats
+HP Bypass
-Emulate
Manufacturer:DEL
Product Code:41003
Serial#:7011007
Week:52 Year:2007
-EDID Formats
+HP Bypass
-Emulate
