881/882 Video Test Generator User Guide (Rev A.22)
125
8. On the target generator, press the
Tools key. The Tools menu appears on the
generator’s display as shown below.
9. Choose the
System item by pressing the adjacent soft key. The System menu appears
on the generator’s display as shown below.
ite
10. Choose the
Clone item by pressing the adjacent soft key. The Clone menu appears on
the generator’s display as shown below.
11. Choose the
Restore item by pressing the adjacent soft key.
A progress indicator appears.
12. Restart the generator from flash memory.
Cloning a generator using the Generator FTP Browser
This section provides procedures for cloning a generator with a PC directly connected to a
generator. You will find this cloning method procedure useful if you do not have a PC Card.
To complete this procedure you connect the Ethernet crossover cable to the Ethernet
ports of both the PC and the generator. If your generators are networked over an Ethernet
LAN, see “
Cloning generators using the generator FTP Browser
During this procedure, you will copy the files from the source generator to the PC,
disconnect the source generator and connect the target generator, and then copy the files
from the PC to the target generator. You must know the IP address of both generators.
To clone a generator using the Generator FTP Browser:
1. Connect the source generator to the PC using an Ethernet crossover cable between
the Ethernet ports on the PC and the generator.
System
Sequence
Probe
AFC
Analyzer
Reports
ImgShift
CEC
Clock
Clone*
CalFactor
Server
Network
About
Serial
GPib
Capture
Restore
