881/882 Video Test Generator User Guide
(Rev A.22)
1025
Note: The DVSC command can be used to set the swing value between 150 and 1500
mVp-p.
Method
To adjust the swing in 6 mV increments, press the Contents key and then the Options key.
You then enable More and use the +/- increment keys to proceed through the subimages.
Dyna
Description
This image has multiple versions that display different sizes of the same pattern. Version 0
is shown below.
