548 Chapter 16 Testing EDID
2. Press the Source key and choose a valid HDMI or VGA format (for example, DMT0660)
by pressing the adjacent soft key.
Alternatively, to select the format through the command line interface, enter the
following command:
FMTL DMT0660
FMTU
3. Activate the HDMI-H, HDMI-D or VGA interface on the output port as follows:
a. Press the Interface key. A listing of signal interfaces appears on the generator’s
display as shown below.
b. Choose the HDMI-H, HDMI-D or VGA item by pressing the adjacent soft key. The
interface is activated and the port outputs the currently selected image and format.
c. Alternatively, to activate the interface through the command line interface, enter the
following commands:
XVSI 4 // Selects the HDMI-H interface
or
XVSI 3 // Selects the HDMI-D interface
XVSI 9 // Selects the VGA interface
ALLU // Applies the interface setting to the generator
VGA
HDMI-D CVBS
S-VIDEO
SDI
*
HDMI-H
