881/882 Video Test Generator User Guide
(Rev A.22)
469
DPTX:SATW
DPTX:SATW?
Sets the wait time in second between link layer test.
Queries the wait time in seconds of this parameter.
Arguments
Valid Values
Wait time: 1 to 60 seconds
Examples
Syntax
Explanation
Command: DPTX:SATW 3
Causes the link layer test suite to wait 3 sec-
onds between each test.
Query: DPTX:SATW?
Queries for the current value of the SATW
parameter
DPTX:SCRG
DPTX:SCRG?
Specifies the whether scrambling is enabled or disabled.
Queries for the current setting of the SCRG scrambling parameter.
Arguments
Valid Values
Enable: 0 = disables scrambling
1 = enables scrambling
Examples
Syntax
Explanation
Command: DPTX:SCRG 1
Enables scrambling.
Query: DPTX:SCRG?
Queries to determine is scrambling is
enabled or disabled.
DPTX:SLAC
DPTX:SLAC?
Sets the number of main link lanes to use.
Queries for the current setting for the lanes.
Arguments
Valid Values
Lanes: 1 = one lane
2 = two lanes
4 = four lanes
Examples
Syntax
Explanation
Command: DPTX:SLAC 1
Sets the number of lanes to 1. When
DPRX:LNKU is run, it will use this setting.
Query: DPTX:SLAC?
Queries for the current value of the number of
lanes (SLAC) parameter.
DPTX:SLNR
DPTX:SLNR?
Sets the link rate to low (1.62Gb/s) or high (2.7Gb/s).
Queries for the current value of the link rate parameter.
Arguments
Valid Values
Link rate: 0 = 1.62Gb/s
1 = 2.7Gb/s
Examples
Syntax
Explanation
