881/882 Video Test Generator User Guide
(Rev A.22)
517
To generate a report of EDID data received from a connected display device:
1. Connect the display under test to the generator.
2. Press the
Tools key. The Tools menu appears on the generator’s display as shown
below.
3. Press the
Reports key. The Reports menu appears on the generator’s display as
shown below.
4. Choose the
EDID item by pressing the adjacent soft key. The EDID reports menu
appears on the generator’s display as shown below.
Note: Be sure that you have transferred any existing EDID reports to your PC.
Otherwise, generating a new report overwrites the existing report.
5. Choose
!DataRpt item by pressing the adjacent soft key. An EDID Information Report
is generated and stored on the PCMCIA card in the
/card0/Library/Reports/Edid_Data.htm file.
6. Open the FTP Browser on the generator and select a suitable directory on your PC to
store the report.
7. Using the FTP Browser, transfer the report from the generator PCMCIA card to your PC
like shown below.
Note: Make sure to change the names of any existing reports in the directory on your
PC to avoid overwritting existing reports.
System
Sequence
Probe
AFC
Analyzer
Reports
ImgShift
EDID
Packets
!DataRpt
!CompRpt
EditCDF
