881/882 Video Test Generator User Guide (Rev A.22) 41
Use the following table to connect the 882D generator to the display under test.
Selecting interface type
After making the physical connection, you are ready to select the interface type for your
display under test.
You can select the interface using either the front panel keys or the command line
interface. The interface is one of the following:
• VGA - For testing analog VESA displays on the 882C.
• DVI-A - For testing analog VESA displays on the 882D.
• CVBS - For testing composite analog consumer electronic displays.
• S-Video - For testing composite (separate luma and chroma) consumer electronic
displays.
• DVI-D - For testing digital VESA displays (dual link) on the 882D.
Display type Signal type Port (Interface) Cable
Information
Technology
(IT) Computer - VESA
(DMT, CVT) Analog component
RGB DVI-A with DVI to
VGA adapter VGA to VGA
Computer - VESA
DDWG Digital component
RGB DVI for single and
dual link or HDMI
OUT (HDMI-D) for
single link only DVI to DVI
cable for DVI
connector or
HDMI to DVI for
HDMI-D con-
nector
Consumer
Equipment
(CE) SDTV - ITU-470-6
baseband Analog composite
CVBS CVBS BNC to RCA
75 Ohm
SDTV - ITU-470-6
baseband Analog composite
S-Video SVIDEO S-Video
(miniDin)
SDTV - CEA-861B Analog component
YPbPr
DVI with DVI to
VGA adapter VGA to RCA 1
1. Optional cable available from Quantum Data.
HDTV -
CEA-861C DVI for single and dual
link or HDMI OUT
(HDMI-D) for single link
only HDMI OUT
(HDMI-D) DVI to DVI
cable for DVI
connector or
HDMI to DVI for
HDMI-D con-
nector
HDTV -
CEA-861C Digital component
HDMI RGB and YCbCr HDMI OUT
(HDMI-H) HDMI to HDMI
Profes-
sional AV SDI
(SMPTE-259M)
and HD-SDI
(SMPTE-292M-C) Digital component
YCbCr SDI/HD-SDI BNC Coax
