To enable catalogs in the Content list using the front panel:
1. Press the Content key. The list of images appears on the generator’s
display.
2. Press the Options key repeatedly until the Library folder appears
on the generator’s display as shown below:
3. Choose the Library item by pressing the adjacent soft key. The image library
appears as shown below. Each item in the image library is an image catalog.
4. Press the soft key adjacent to a catalog to enable or disable it. A + sign next to the item indicates
the item is enabled; a - sign indicates it is disabled.
5. Press the Content key to see the images in the selected catalogs.
To remove an image from a catalog:
1. Establish a session with the generator using either HyperTerminal over a serial
connection or Telnet over an Ethernet LAN.see “ Establishing a terminal session with
the generator ” on page 31 or “ Establishing a Telnet session with the generator ” on page
34.
2. To remove an image from a catalog, enter the following commands:
DIRL /tffs0/Library/ImageLib/TVImages // loads the TVImages catalog
DIRT ContentLib // identifies directory as a content directory
DIRB // begins a directory editing session
NAMK /cache0/Library/Images/TVImages/SMPTE133.img
Or...
NAMY 1 // deletes SMPTE133 (index 1)
DIRE // ends the directory editing session
DIRS // saves the catalog
Library
-TVImages FPDImages-
SMPTE133 SMPTEBar
TVBar100 PulseBar
Regulate Geom_1
