6. To change the flow control state, do the following:
a. Position the blinking cursor on the flow control setting. To do this, press the soft
keys adjacent to the arrow by the flow control setting until the cursor appears on
the current flow control setting (N, H, or T).
b. Press the + or - keys to change the setting.
7. To change the number of data bits, do the following:
a. Press the soft keys adjacent to the third row until CHAR appears. The current data
bits setting is shown in the bottom row.
b. Position the blinking cursor on the CHAR setting. To do this, press the soft keys
adjacent to the arrow by the CHAR setting until the cursor appears on the current
data bits setting.
c. Press the + or - keys to adjust the setting up or down.
8. To change the parity, do the following:
a. Position the blinking cursor on the PRTY setting. To do this, press the soft keys
adjacent to the arrow by the PRTY setting until the cursor appears on the current
parity setting.
b. Press the + or - keys to adjust the setting up or down.
9. To change the stop bits, do the following:
a. Position the blinking cursor on the STOP setting. To do this, press the soft keys
adjacent to the arrow by the STOP setting until the cursor appears on the current
stop bits setting.
b. Press the + or - keys to adjust the setting up or down.
10. To save the changes, press the Enter (Options) key. The following choices appear on
the generator’s display:
To save the changes, choose the Yes item by pressing the adjacent soft key.
To exit without saving the changes, choose the No item.
To return to the previous screen without saving the changes, choose the Back item.
Serial Port
Set Params
<- CHAR PRTY STOP
8 N 1 ->
Apply Settings?
Back
Yes No
