526 Chapter 16 Testing EDID
3. Activate the HDMI-H interface on the output port as follows:
Note: You may have to select a valid HDMI format at this point.
a. Press the Interface key. A listing of signal interfaces appears on the generator’s
display as shown below.
b. Choose the HDMI-H item by pressing the adjacent soft key. The interface is
activated and the port outputs the currently selected image and format.
c. Alternatively, to activate the interface through the command line interface, enter the
following commands:
XVSI 4 // Selects the HDMI-H interface
ALLU // Applies the interface setting to the generator
4. Press the Sink key, and then press the Options key. The following menu appears on
the generator’s display:
Cho
5. Choose the CDF item by pressing the adjacent soft key. The CDF parameters appear
on the generator’s display as shown below.
Cho.
VGA
HDMI-D CVBS
S-VIDEO
SDI
*
HDMI-H
VGA
HDMI-D CVBS
S-VIDEO
SDI *HDMI-H
-EDID Formats CDF
+HP Bypass
-Emulate
0:HDMI Output Count
1:HDMI Input Port
-CEC Root Device
>Primary AR: 4:3
