582 Chapter 17 Testing Lipsync
the generator ” on page 31 or “ Establishing a Telnet session with the generator ” on page
34.
2. Perform steps 2 - 6 of “ Testing HDMI source device for Lipsync handling ” on page 579
to set up analyzer for lipsync testing.
3. Press the Tools key. The Tools menu appears on the generator’s display as shown
below.
4. Choose the Analyzer item by pressing the adjacent soft key. The Analyzer menu
appears on the generator’s display as shown below.
5. Choose the LipSync item by pressing the adjacent soft key. The LIPSYNC menu
appears on the generator’s display as shown below.
Note: Be sure that you have transferred any existing Lipsync reports to your PC.
Otherwise, generating a new report overwrites the existing report.
6. Choose !Report item by pressing the adjacent soft key. A Lipsync Measurements
Report is generated and stored on the PCMCIA card in the
/card0/Library/Reports/LipSync_Data.htm file.
Alternatively, to generate a lipsync measurement report through the command line
interface, enter the following command:
LSAX:RPTG 1 // generate lipsync measurement report
LSAX:LSGU // Activates lipsync analyzer
7. Open the FTP Browser on the generator and select a suitable directory on your PC to
store the report.
8. Using the FTP Browser, transfer the report from the generator PCMCIA card to your PC
like shown below.
System
Sequence
Probe
AFC
Analyzer
Reports
ImgShift
Timing
CableTest PIX-ERR
PRN-ERR
*
ViewPix LipSync
LIPSYNC
Measure Exit
!Report
! !
