881/882 Video Test Generator User Guide (Rev A.22) 577
8. (Optional when using LipSync image only) To adjust vertical line spacing (thus
changing frequency of audible beeps), follow these steps:
a. Choose More by pressing the adjacent soft key. A + and Rendition appears next
to the item.
b. Press + and - keys to adjust vertical line interval. Changing the interval adjusts
calculated moving time for white box between two lines.
Alternatively, to adjust vertical line intercal using the command line interface, enter the
following commands:
ISUB 1 // Enables sub images
IVER 1 // Specifies the first image version
IMGU // Activates the image version
c. When you are finished, disable image versions by pressing the Options key and
choosing More until a - appears next to it.
Alternatively, to disable image versions using the command line interface, enter the
following command:
ISUB 0 // Disables sub images
+More Rendition: 000
+LipSync
Red+
-NoGamma Green+
-Noise Blue+
