881/882 Video Test Generator User Guide (Rev A.22) 615
The following table describes the test parameters and their settings (gray = N/A).
7. Select Sink device by pressing the adjacent soft key to specify that the device under
test is a sink.
The following is displayed on the generator’s LCD.
Alternatively, you can specify the device under test as a sink using the following
commands:
Parameter Explanation
DUT type The type of device under test. This can be one of Sink,
Source, Repeater, Repeater3AB, or Repeater3C. For
this test, select Sink.
Source Max KSV Specifies the maximum number of KSVs the source can
read. The valid values are 1 through 127.
Source Authentication Control Specifies the number of times a source DUT attempts
authentication before transitioning into the authentica-
tion state. The valid values are 1 or greater.
Source Out Only Repeater Indicates whether the DUT outputs contents to a
repeater to which no downstream device is connected.
The values are + for yes and - for no.
Sink 1.1 Features Supported Indicates whether the DUT supports Advanced_Cipher
mode and Enhanced Link Verification. The values are +
for yes and - for no.
Sink 1.1 Audio Supported Indicates whether the DUT supports audio output. The
values are + for yes and - for no.
Repeater 1.1 Features Supported Indicates whether supports Advanced_Cipher mode
and Enhanced Link Verification. The values are + for yes
and - for no.
Repeater Audio Support Indicates whether the DUT supports audio output. The
values are + for yes and - for no.
Repeater HPD Pulse Indicates whether the DUT has the capability to output
HPD pulse by user operation. The values are + for yes
and - for no.
Repeater Max KSV Specifies the maximum number of KSVs the repeater
can read. The valid values are 2 through 127.
Repeater Out OnlyRep Indicates whether the DUT outputs content to the down-
stream repeater that has no downstream device con-
nected. The values are + for yes and - for no.
Sink :DUT Type
0
1
+Source_Out_OnlyRep :Source_Authe_Cnt
:Source_Max_KSV
