604 Chapter 18 Testing HDCP
There are several configurations depending on what type of HDCP device you are testing.
Procedures for each are provided below.
Running HDCP compliance test on HDMI transmitters
To run the 1A and 1B series HDCP compliance tests on an HDMI source (transmitter):
Note: For the 882E, the 1A-08 test requires that you use the SRM disc for the 1A-08 test
if the source device has an optical drive. Refer to “
To run the 1A-08 HDCP compliance test
using the SRM disc: ” on page 611.
40 3C_II_04 (Repeater Upstream
w/Transmitter) (Between HDMI
Capable Transmitter and
Repeater) Regular Procedure: HPD After Starting Third Part
of Authentication
41 3C_II_05 (Repeater Upstream
w/Transmitter) (Between HDMI
Capable Transmitter and
Repeater) Irregular Procedure: (Second Part of
Authentication) Verify V'
42 3C_II_06 (Repeater Upstream
w/Transmitter) (Between HDMI
Capable Transmitter and
Repeater) Irregular Procedure: (Second Part of
Authentication) DEVICE_COUNT
43 3C_II_07 (Repeater Upstream
w/Transmitter) (Between HDMI
Capable Transmitter and
Repeater) Irregular Procedure: (Second Part of
Authentication) DEPTH
44 3C_II_08 (Repeater Upstream
w/Transmitter) (Between HDMI
Capable Transmitter and
Repeater) Irregular Procedure: (Second Part of
Authentication) MAX_DEVS_EXCEEDED
45 3C_II_09 (Repeater Upstream
w/Transmitter) (Between HDMI
Capable Transmitter and
Repeater) Irregular Procedure: (Second Part of
Authentication) MAX_CASCADE_EXCEEDED
Index Test Description
