Quantum Data 881 User Manual

Page 686

570

Chapter 19 Using Special Sync Output

2. Choose the

Probe item by pressing the adjacent soft key. The current probe settings

appear on the generator’s display as shown below:

3. Press the

Settings key to access the setting for the probe pulse width. The following

appears on the generator’s display:

4. Set the probe width as follows

a. Position the blinking cursor on the digit you want to change. To do this, press the

soft key adjacent to the arrow by the width value to move the cursor left or right until
it appears on the digit you want to change.

b. Adjust the value of the digit up or down by pressing the + or - keys. Repeat for each

you want to change.

5. To save the changes, press the

Enter (Options) key. The following choices appear on

the generator’s display:

To save the changes, choose the

Yes item by pressing the adjacent soft key.

To exit without saving the changes, choose the

No item.

To return to the previous screen without saving the changes, choose the

Back item.

6. Press the

Options key. The options for setting the line or lines on which the probe pulse

will occur appears on the generator’s display:

7. Press the soft key adjacent to the desired option, as follows:

•

OneLine: Probe pulse occurs once per frame.

•

AllActive: Probe pulse occurs on every active line in the frame.

•

AllLines: Probe pulse occurs on every line in the frame.

Left

P:0000 Exp

Right X:0000

L:0000

Down

Y:0000 100

Probe Tool

Probe Width
PSPW
<- 136

Apply Settings?

Back
Yes No

*OneLine

Exit

AllActive

AllLines

Visible-
