881/882 Video Test Generator User Guide (Rev A.22) 325
FMTL format_name
FMTU
3. Press the Options key and select xvYCC colorimetry.
There are two color standards, xvYCC601 and xvYCC709. The appropriate one is
selected depending on the format.
Alternatively, you can load the xvYCC color space with the following command:
DVST 16
FMTU
4. Press the Content key and select the desired Munsell images as shown in the following
menu.
Alternatively, you can load the format with the following command:
IMGL MnslClr
IMGU
5. Enable and view image versions as follows:
a. Press the Options key. The following menu appears on the generator’s display:
b. Choose the More item by pressing the adjacent soft key until a + appears next to
More and Rendition appears on the other side of the menu.
c. Press the + and - keys to advance through the image versions. Each version shows
the format parameters for a different format in the Source list.
Alternatively, to enable and view image versions using the command line interface,
enter the following commands:
ISUB 1 // Enables sub images
RGB 8-bits
YCbCr 10-bits
*xvYCC 12-bits
*4:4:4 4:2:2
MESony_R MnslCLR
*MnslGM MnslPG
MoireX MoireX33
MoireY MoireY33
-More
Red+
-NoGamma Green+
-Noise Blue+
+More Rendition: 000
Red+
-NoGamma Green+
-Noise Blue+
