7. Click on the
Sink tab to access the window to run the tests.
The source window is shown below:
YCbCr 4:4:4 check
box
Defines whether the sink device under test supports the YCbCr
color mode with 4:4:4 sampling.
YCbCr 4:2:2 check
box
Defines whether the sink device under test supports the YCbCr
color mode with 4:2:2 sampling.
VESA Timings List
select box
Enables you to select the VESA formats (timings) that the sink
device under test supports. Use the Shift key or the Control key to
select multiple timings.
CEA Timings List
select box
Enables you to select the CEA related formats (timings) that the
sink device under test supports. Use the Shift key or the Control
key to select multiple timings.
Max Bits per
Component pull
down box
Defines the maximum bits per component that the sink device
under test supports.
Test Automation
check box
)
*+ +
+
%
, )
- .
-//
)
Receiver Capability
Field
'
+
01
,+ &
2 % / 0
1, )
+
+
01
+ + - +
3+
+
4
%
Function/Field
Function
