881/882 Video Test Generator User Guide (Rev A.22) 603
28 3B_04 (Repeater Downstream
w/Repeater) Irregular Procedure: (Second Part of
Authentication) MAX_DEVS_EXCEEDED
29 3B_05 (Repeater Downstream
w/Repeater) Irregular Procedure: (Second Part of
Authentication) MAX_CASCADE_EXCEEDED
30 3C_I_01 (Repeater Upstream
w/Transmitter) (Between HDMI
Capable Transmitter and HDMI
Capable Receiver) Regular Procedure: Transmitter – DUT –
Receiver
31 3C_I_02 (Repeater Upstream
w/Transmitter) (Between HDMI
Capable Transmitter and HDMI
Capable Receiver) Regular Procedure: HPD Pulse Output Caused
By User Operation
32 3C_I_03 (Repeater Upstream
w/Transmitter) (Between HDMI
Capable Transmitter and HDMI
Capable Receiver) Irregular Procedure: (First Part of Authentication)
New Authentication
33 3C_I_04 (Repeater Upstream
w/Transmitter) (Between HDMI
Capable Transmitter and HDMI
Capable Receiver) Irregular Procedure: (Second Part of
Authentication) New Authentication
34 3C_I_05 (Repeater Upstream
w/Transmitter) (Between HDMI
Capable Transmitter and HDMI
Capable Receiver) Irregular Procedure: (Third Part of
Authentication) New Authentication
35 3C_I_06 (Repeater Upstream
w/Transmitter) (Between HDMI
Capable Transmitter and HDMI
Capable Receiver) Irregular Procedure: (Second Part of
Authentication) Verify Bksv
36 3C_I_07 (Repeater Upstream
w/Transmitter) (Between HDMI
Capable Transmitter and HDMI
Capable Receiver) Irregular Procedure: (Second Part of
Authentication) Verify R0'
37 3C_II_01 (Repeater Upstream
w/Transmitter) (Between HDMI
Capable Transmitter and
Repeater) Regular Procedure: Transmitter – DUT –
Repeater-Receiver
38 3C_II_02 (Repeater Upstream
w/Transmitter) (Between HDMI
Capable Transmitter and
Repeater) Regular Procedure: HPD After Writing Aksv
39 3C_II_03 (Repeater Upstream
w/Transmitter) (Between HDMI
Capable Transmitter and
Repeater) Regular Procedure: HPD After Reading R0'
Index Test Description
